PLCC SOCKET DIP & SMT

MATERIAL
Insulator : Thermoplastic {UL 94V-0}
Color : See ordering Information
Contact : Copper Alloy
Contact Plated : See ordering information

SPECIFICATION
Storage Temperature : -20-70¡æ
Operating Temperature : 0-85¡æ
Contact Resistance : 20m ¦¸ max.(initial)
Insulation Resistance : 1,000M ¦¸ min
Dielectric Withstanding Voltage : AC1,000V pm
