OX 15EDGR

Material
Pin header: Brass, Tin plated
Housing: PBT, UL94V-0

Electrical
Rated voltage: 300V
Rated current: 8A
Contact resistance: 20m¦¸
Insulation resistance: 5000m¦¸/1000V
Withstanding voltage: AC 1500V/1 Min

Mechanical
Temp. Range: -40¡æ~ +130¡æ
MAX Soldering: +250¡æ, for 5 Sec.
