OX 301

Material
Screws: M2.5 steel Zinc plated
Wire guard: Phosphor bronze
Ni plated or stainless steel
Pin header: Brass, Tin plated
Housing: PBT, UL94V-0

Electrical
Rated voltage: 250V
Rated current: 16A
Contact resistance: 20m¦¸
Insulation resistance: 5000m¦¸/1000V
Withstanding voltage: AC 1500V/1 Min
Wire range: 22-14AWG 2.5mm2

Mechanical
Temp. Range: -30¡æ~ +120¡æ
MAX Soldering: +250¡æ, for 5 Sec.
Torque: 0.4Nm(3.6lb.in)
Strip length: 4.5-5mm
